Axis 02135-003 network video recorder Black
- 5-year warranty; Compact recorder with integrated PoE switch; Easy to install and operate; Surveillance-grade hard drive; USB port for exporting video
AXIS S3008 Recorder is a compact recorder with an integrated PoE switch for up to 8 cameras. It provides reliable recording thanks to the surveillance-grade hard drive. This high-performance recorder offers gigabit uplink for video recordings in ultra-high definition and includes a 5-year warranty. The recorder is supported by the AXIS Companion video management software and mobile app.
| Performance | |
|---|---|
| Audio system | 1-way |
| Input bandwidth | 160 Mbit/s |
| Video formats supported | AVC, H.264, H.265, HEVC, MPEG4 |
| Audio formats supported | AAC |
| Hard drive | |
|---|---|
| HDD capacity | 8 TB |
| Number of HDDs installed | 1 |
| Ports & interfaces | |
|---|---|
| Supported network protocols | IPv4/v6, HTTP, SSL/TLS, QoS, SFTP, SMTP, Bonjour, UPnP, DNS, NTP, TCP, UDP, IGMP, ICMP, DHCPv4/v6, ARP, SSH |
| Networking standards | IEEE 802.1x, IEEE 802.3af, IEEE 802.3at |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
| Power over Ethernet (PoE) ports quantity | 8 |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Power over Ethernet (PoE) | Yes |
| Copper ethernet cabling technology | 10BASE-T, 100BASE-TX |
| Ethernet LAN (RJ-45) ports | 9 |
| Features | |
|---|---|
| Certification | CISPR 24, CISPR 35, EAC, EN 55024, EN 55032 Class A, EN 61000-3-2, EN 61000-3-3, EN 61000-6-1, EN 61000-6-2, FCC Part 15 Subpart B Class A, ICES-003 Class A, KC KN32 Class A, KC KN35, RCM AS/NZS CISPR 32 Class A, VCC1 Class A, IEC/EN 62368-1, UL 62368–1, IEC 60068-2-1, IEC 60068-2-14, IEC 60068-2-2, IEC 60068-2-27, IEC 60068-2-6, IEC 60068-2-78, IEC/EN 60529 IP3X |
| Product colour | Black |
| Power | |
|---|---|
| Output current | 1.88 A |
| Total Power over Ethernet (PoE) budget | 60 W |
| Output voltage | 48 V |
| AC input frequency | 50 – 60 Hz |
| AC input voltage | 100-240 V |
| Power consumption (max) | 90 W |
| Operational conditions | |
|---|---|
| Storage relative humidity (H-H) | 5 – 95% |
| Storage temperature (T-T) | 10 – 85 °C |
| Operating relative humidity (H-H) | -40 – 65% |
| Operating temperature (T-T) | 0 – 45 °C |
| Weight & dimensions | |
|---|---|
| Weight | 1.45 kg |
| Height | 53 mm |
| Depth | 180 mm |
| Width | 180 mm |
| Packaging content | |
|---|---|
| AC adapter included | Yes |
| Quick installation guide | Yes |
