Belkin F1DN1CCBL-CPN6T KVM extender Transmitter & receiver
- All-in-one Secure KVM dock with integrated cables
- SKVM Side: 1x DisplayPort™ 1.2 (male) and 1x USB Type-B (male) 6 ft. (1.8 m) cables
- Supports video up to single-head 4K@60Hz and dual-head 4K@30Hz
- Host/Source Side: 1x USB-C 3.1 Gen 2 10 Gbps (male) 3 ft. (0.9 m) cable
- USB-C (female) Power Delivery 2.0-compliant port that supports pass-through power to channel up to 100W from an outlet to your device
- Charge your laptop while working with the USB-C (female) power
- Ethernet up to 1 G network traffic, cable not included
- Improves deployment and user experience by eliminating quality and performance issues from non-Belkin or aftermarket docks
- High-retention connectors as standard
- TAA compliant
Docks typically add more ports to work with, but this can adversely affect security. Belkin TAA-compliant docking stations offer built-in cables and less ports, increasing security without disrupting compatibility.
Belkin purpose-built docks create a secure, expanded workspace that allows you to connect up to two displays through DisplayPort™. The KVM dock offers up to 100W of pass-through power and 1 Gbps data transfer speeds, giving you the ability to connect and work while charging your laptop.
View everything in high definition and work on multiple applications across your screens. This USB-C® dock allows you to enjoy sharper-looking, more detailed images, and visualize content across extended displays via monitor resolutions up to 4K@60Hz.
The combination of the Belkin Secure KVM and dock allows you to connect a keyboard, video and mouse, while reducing desktop clutter with a single USB-C cable connection to the host.
| Features |
| Product colour |
Black |
| Maximum refresh rate |
60 Hz |
| Maximum digital resolution |
3840 x 2160 pixels |
| Cable types supported |
Cat6 |
| Connectivity technology |
Wired |
| Type |
Transmitter & receiver |
| Transmitter |
| Transmitter USB Type-B ports quantity |
1 |
| Number of displays supported |
1 |
| Transmitter video port type |
DisplayPort |
| Receiver |
| RJ-45 ports quantity (receiver) |
1 |
| Receiver local keyboard/mouse port type |
USB |
| Ports & interfaces |
| USB data transfer rates |
10000 Mbit/s |
| USB port type |
USB Type-C |
| Power |
| Power consumption (receiver) (max) |
100 W |
| Power plug type |
Type C |
| Packaging content |
| Quick installation guide |
Yes |
| Cables included |
USB Type-C to DisplayPort, USB Type-C to USB Type-B |
| Sustainability |
| Sustainability compliance |
Yes |
| Other features |
| Compliance certificates |
Trade Agreements Act (TAA) |
| Warranty period |
3 year(s) |
