Broadcom eHBA 9600-16e interface cards/adapter Internal SAS, SATA
- Low profile, half-length x8 PCIe Gen 4.0 adapter
- Connect up to 240 SAS/SATA devices or 32 NVMe devices
- Hardware Secure Boot and SPDM Attestation support
- SMART monitoring
- Drive temperature monitoring
- SafeStore key management for attached SEDs
- Universal Bay Management (UBM) Ready
The 9600-16e Tri-Mode, PCIe Gen 4.0 enhanced HBA (eHBA) is ideal for increased connectivity and maximum performance for enterprise data center flexibility.
With increased bandwidth and IOPS performance compared to previous generations, the 9600-16e eHBA delivers the performance and scalability needed by critical applications.
| Ports & interfaces |
| External mini-SAS HD ports |
4 |
| NVMe |
Yes |
| Expansion card standard |
PCIe 4.0 |
| Expansion card form factor |
Full-height / Low-profile |
| Output interface |
SAS, SATA |
| Host interface |
PCIe |
| Design |
| Certification |
Australia/New Zealand RCM (AS/NZS CISPR 32; CISPR 32:2015, Class A; AS/NZS CISPR 32:2015, Class A), Canada EMC (ICES-003:2016 Issue 6: 2016, Class A; CAN/CSA CISPR 22-10; CISPR 22:2008), Europe (CE) (EN 55024, EN 55032, EN 55035; EN 55032:2015 +AC:2016, Class A; EN 55024:2010 +A1:2015; EN 55035:2017 +A11:2020), Korea (KN32/KN35), Taiwan BSMI (CNS 13438; CNS15663), USA/Canada Safety (UL Listed) (UL 62368-1, Second Edition; CAN/CSA C22.2 No. 62368-1-14), USA/Canada (FCC) (47 CFR FCC Part 15, Subpart B, Class A; ANSI C63.4:2014; CISPR 32:2008) CB (IEC 62368-1:2014 (Second edition); EN 62368-1:2014+A11: 2017), Japan (V-3/2015.04, Class A; V-4/2012.04; VCCI-CISPR 32:2016; CISPR 32:2015), Morocco (CMIM) (EN 55024, EN 55032, EN 55035; EN 55032:2015 +AC:2016, Class A; EN 55024:2010 +A1:2015; EN 55035:2017 +A11:2020) |
| Mean time between failures (MTBF) |
5000000 h |
| Product colour |
Black, Green, Silver |
| Internal |
Yes |
| Features |
| S.M.A.R.T. support |
Yes |
| Data transfer rate (max) |
22.5 Gbit/s |
| Power |
| Power consumption (typical) |
17 W |
| Operational conditions |
| Operating relative humidity (H-H) |
5 – 90% |
| Operating temperature (T-T) |
0 – 55 °C |
| System requirements |
| Other operating systems supported |
VMware vSphere ESXi |
| Server operating systems supported |
SUSE Linux Enterprise Server |
| Linux operating systems supported |
Yes |
| Windows operating systems supported |
Yes |
| Technical details |
| Sustainability compliance |
Yes |
| Warranty period |
3 year(s) |
| Compliance certificates |
RoHS, WEEE |
| Weight & dimensions |
| Depth |
68.8 mm |
| Width |
167.5 mm |
| Packaging data |
| Mounting brackets included |
Yes |
| Quantity per pack |
1 pc(s) |
