Datamax O’Neil MP-Series Compact4 Mobile label printer Direct thermal 300 x 300 DPI 125 mm/sec Wired & Wireless
- Direct thermal
- 300 x 300 DPI
- Print speed: 125 mm/sec
- Built-in barcodes: EAN13, PDF417
- Connectivity technology: Wired & Wireless
- USB port
- 4.5 kg
The Compact4 Mobile is designed for installation on forklift trucks and mobile stations. It can operate from a connection to a forklift’s battery and its vibrationproof design makes it the perfect choice for warehousing logistics.
– Small but Mighty: The Compact4 printers have an incredibly small footprint which allows them to be used in applications where space is limited. Their compact size takes up less than half the space of a traditional desktop label printer but with the same duty cycle and strength.
– Rugged: The Compact4 printers are constructed on a solid cast metal frame and protected with metal die cast covers. Unlike other small printers, the Compact4 series are industrial printers that are built to withstand the rigors of a warehouse or high volume printing application.
– Range: The Nova series of printers offer robust, high-performance range of thermal transfer and direct thermal printers with 3 different print widths: 4.1” [104 mm] – 6.6” [168 mm] – 8.5” [216 mm], print resolutions of 200 or 300 dpi, and print speed up to 9.8”/s [up to 250 mm/s]
– Media loading is unlike any other printer in the market. The levers are large and easy to manage — so easy that the operation can be done single handed while wearing a leather or latex glove. The paper path is slotted through the side of the printer with no covers to open or clamshells to unlock. Loading media doesn’t get any easier.
– Software: Labelpoint is a simple yet powerful command language that controls the Compact4 and Nova printers. TeraTerm is an easy to use DOS terminal program for configuring these printers. MP Design is powerful label design software which programs label formats in the printers native command language, Labelpoint. MP Design software comes standard with Compact and Nova printers.
| Printing |
| Print speed |
125 mm/sec |
| Maximum resolution |
300 x 300 DPI |
| Print technology |
Direct thermal |
| Paper handling |
| Media thickness |
0.58 – 0.18 mm |
| Supported paper width |
40 – 115 mm |
| Maximum roll diameter |
10 cm |
| Media thickness (imperial) |
0.0023 – 0.0071″ |
| Autocutter |
No |
| Ports & interfaces |
| RS-232 ports |
1 |
| Parallel ports quantity |
1 |
| USB 2.0 ports quantity |
1 |
| USB port |
Yes |
| Connectivity technology |
Wired & Wireless |
| Performance |
| Number of fonts |
10 |
| Fixed length |
Yes |
| Built-in barcodes |
EAN13, PDF417 |
| Flash memory |
4 MB |
| Internal memory |
8 MB |
| Design |
| Product colour |
Grey |
| Power |
| Power requirements |
24-48 VDC, 120 VA |
| General |
| Product family |
MP-Series |
| System requirements |
| Compatible operating systems |
Windows NT, XP, Vista |
| Mac compatibility |
No |
| Operational conditions |
| Operating temperature (T-T) |
5 – 40 °C |
| Operating relative humidity (H-H) |
20 – 85% |
| Weight & dimensions |
| Weight |
4.5 kg |
| Height |
125 mm |
| Depth |
260 mm |
| Width |
230 mm |
| Logistics data |
| Harmonized System (HS) code |
84433210 |
| Other features |
| Network ready |
Yes |
