Kensington SD4842P EQ USB-C 10Gbps Triple Video Driverless Docking Station with 100W Power Delivery
- Docking
- Host interface: USB 3.2 Gen 2 (3.1 Gen 2) Type-C
- USB Power Delivery (USB PD)
- Ethernet LAN 10,100,1000 Mbit/s
- Cable lock slot
- Plug and Play
| Ports & interfaces | |
|---|---|
| DC-in jack | Yes |
| USB Type-C DisplayPort Alternate Mode | Yes |
| HDCP | Yes |
| Headphone connectivity | 3.5 mm |
| Headphone outputs | 1 |
| Combo headphone/mic port | Yes |
| DisplayPort version | 1.4 |
| DisplayPorts quantity | 1 |
| HDMI version | 2.1 |
| HDMI ports quantity | 2 |
| USB Power Delivery revision | 3.0 |
| USB Power Delivery up to | 100 W |
| USB Power Delivery (USB PD) | Yes |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 2 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 3 |
| Host interface | USB 3.2 Gen 2 (3.1 Gen 2) Type-C |
| Connectivity technology | Docking |
| Network | |
|---|---|
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Ethernet LAN (RJ-45) ports | 1 |
| Ethernet LAN | Yes |
| Performance | |
|---|---|
| Country of origin | Vietnam |
| LED indicators | Yes |
| Plug and Play | Yes |
| Housing material | Acrylonitrile butadiene styrene (ABS), Polycarbonate (PC) |
| On/off switch | Yes |
| Cable lock slot type | Kensington, Nano |
| Cable lock slot | Yes |
| Number of displays supported | 3 |
| Maximum refresh rate | 120 Hz |
| HD type | 8K Ultra HD |
| Data transfer rate | 10 Gbit/s |
| Card reader integrated | No |
| Product colour | Black |
| Power | |
|---|---|
| Compatible power plug types | EU, UK |
| Output voltage | 21 V |
| Output current | 7.1 A |
| Input current | 2.5 A |
| AC input voltage | 100 – 240 V |
| Power source type | DC |
| Software | |
|---|---|
| Windows operating systems supported | Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 11, Windows 11 Enterprise, Windows 11 Enterprise x64, Windows 11 Home, Windows 11 Pro, Windows 11 x64 |
| Operational conditions | |
|---|---|
| Operating relative humidity (H-H) | 0 – 55% |
| Storage temperature (T-T) | -18 – 60 °C |
| Operating temperature (T-T) | 0 – 40 °C |
| Sustainability | |
|---|---|
| Sustainability compliance | Yes |
| Sustainability certificates | ErP |
| Weight & dimensions | |
|---|---|
| Weight | 293 g |
| Height | 36 mm |
| Depth | 104 mm |
| Width | 195 mm |
| Packaging data | |
|---|---|
| Package weight | 1.15 kg |
| Package height | 100 mm |
| Package depth | 110 mm |
| Package width | 245 mm |
| Packaging content | |
|---|---|
| Cables included | AC |
| AC adapter included | Yes |
| Quick start guide | Yes |
| Warranty card | Yes |
| Technical details | |
|---|---|
| Compliance certificates | CB, CE, Federal Communications Commission (FCC), RCM, RoHS, UKCA, VCCI |
| Logistics data | |
|---|---|
| Products per master (outer) case | 6 pc(s) |
| Other features | |
|---|---|
| Minimum system requirements | CPU: Intel Core i5 6th generation or aboveMemory: 8Gb or aboveGPU: Intel HD Graphics 620 or above |
