Kingston Technology ValueRAM KVR32S22S6/8 memory module 8 GB 1 x 8 GB DDR4 3200 MHz
- Nominal and dynamic on-die termination (ODT) for data, strobe, and mask signals
- Low-power auto self refresh (LPASR)
- Data bus inversion (DBI) for data bus
- On-die VREFDQ generation and calibration
- Single-rank
- On-board I2 serial presence-detect (SPD) EEPROM
- 8 internal banks; 2 groups of 4 banks each
- Fixed burst chop (BC) of 4 and burst length (BL) of 8 via the mode register set (MRS)
- Terminated control command and address bus
ValueRAM, Kingston’s industry standard memory, delivers award-winning performance and legendary Kingston reliability. When you know what you want, you want ValueRAM.
| Features |
| JEDEC standard |
Yes |
| Lead plating |
Gold |
| Programming power voltage (VPP) |
2.5 V |
| Row active time |
32 ns |
| Refresh row cycle time |
350 ns |
| Row cycle time |
45.75 ns |
| Module configuration |
1024M x 64 |
| Memory voltage |
1.2 V |
| CAS latency |
22 |
| ECC |
No |
| Memory form factor |
260-pin SO-DIMM |
| Component for |
Laptop |
| Memory clock speed |
3200 MHz |
| Internal memory type |
DDR4 |
| Memory layout (modules x size) |
1 x 8 GB |
| Internal memory |
8 GB |
| Buffered memory type |
Unregistered (unbuffered) |
| Operational conditions |
| Storage temperature (T-T) |
-55 – 100 °C |
| Operating temperature (T-T) |
0 – 85 °C |
| General |
| Product family |
ValueRAM |
| Technical details |
| Compliance certificates |
RoHS |
| Sustainability |
| Doesn’t contain |
Halogen |
| Weight & dimensions |
| Height |
30 mm |
| Width |
69.6 mm |
