Lenovo ThinkEdge SE70 Jetson Xavier NX 16 GB LPDDR4-SDRAM 1.02 TB SSD+eMMC Linux Mini PC Black
- Mini PC Black 65 W
- Jetson Xavier NX
- 16 GB LPDDR4-SDRAM 1866 MHz 1 x 16 GB
- 1.02 TB SSD+eMMC
- Ethernet LAN 100,1000 Mbit/s
- Linux
| Processor |
| Number of processors installed |
1 |
| Processor model |
Jetson Xavier NX |
| Processor manufacturer |
Nvidia |
| Memory |
| Memory clock speed |
1866 MHz |
| Memory layout (slots x size) |
1 x 16 GB |
| Internal memory type |
LPDDR4-SDRAM |
| Maximum internal memory |
8 GB |
| Internal memory |
16 GB |
| Storage |
| Card reader integrated |
No |
| SSD form factor |
M.2 |
| SSD interface |
PCI Express 3.0 |
| NVMe |
Yes |
| SSD capacity |
1 TB |
| Number of SSDs installed |
1 |
| Total SSDs capacity |
1 TB |
| Number of storage drives installed |
2 |
| Storage media |
SSD+eMMC |
| Optical drive type |
No |
| Total storage capacity |
1.02 TB |
| Graphics |
| Discrete graphics card model |
Not available |
| On-board graphics card |
Yes |
| Discrete graphics card |
No |
| Network |
| Bluetooth |
No |
| Wi-Fi |
No |
| LAN controller |
Intel® I210-IT |
| Cabling technology |
10/100/1000Base-T(X) |
| Ethernet LAN data rates |
100,1000 Mbit/s |
| Ethernet LAN |
Yes |
| Ports & interfaces |
| Ethernet LAN (RJ-45) ports |
2 |
| HDMI version |
1.4 |
| HDMI ports quantity |
1 |
| Design |
| Product colour |
Black |
| Cable lock slot type |
Kensington |
| Cable lock slot |
Yes |
| VESA mounting |
Yes |
| Volume |
1.6 L |
| Chassis type |
Mini PC |
| Performance |
| Product type |
Mini PC |
| Software |
| Bundled software |
Jetpack v4.4 SDK |
| Operating system installed |
Linux |
| Power |
| Power supply input frequency |
50 – 60 Hz |
| Power supply input voltage |
115 – 230 V |
| Power supply |
65 W |
| Operational conditions |
| Operating temperature (T-T) |
-20 – 60 °C |
| Certificates |
| Certification |
CELJELRoHSREACHWEEEMicrosoft AzureAWS IoT |
| Low halogen |
Yes |
| Weight & dimensions |
| Weight |
1.86 kg |
| Height |
65 mm |
| Depth |
128 mm |
| Width |
191 mm |
| Packaging content |
| Keyboard included |
No |
| Mouse included |
No |
| Display included |
No |
