Lenovo ThinkSystem ST250 V3 server Tower Intel Xeon E E-2468 2.6 GHz 32 GB DDR5-SDRAM 800 W
- Intel Xeon E-2468 (24MB Cache, 2.6GHz)
- 32GB (4800MHz) DDR5-SDRAM (1 x 32)
The Lenovo ThinkSystem ST250 V3 is a mainstream 1-socket tower server that also be rack mounted as a rack server. It is ideal for small-to-medium businesses, remote offices, branch offices, banking and public sector. The server supports the new Intel Xeon E-2400 Series processors, formerly codenamed “Raptor Lake”.
This product guide provides essential presales information to understand the ThinkSystem ST250 V3 server, its key features and specifications, components and options, and configuration guidelines. This guide is intended for technical specialists, sales specialists, sales engineers, IT architects, and other IT professionals who want to learn more about the ST250 V3 and consider its use in IT solutions.
| Processor | |
|---|---|
| Processor cache | 24 MB |
| Processor cores | 8 |
| Performance cores | 8 |
| Processor boost frequency | 5.2 GHz |
| Processor frequency | 2.6 GHz |
| Processor model | E-2468 |
| Processor family | Intel Xeon E |
| Processor manufacturer | Intel |
| Memory | |
|---|---|
| Maximum internal memory | 128 GB |
| Memory slots | 4x DIMM |
| ECC | Yes |
| Memory clock speed | 4800 MHz |
| Memory layout (slots x size) | 1 x 32 GB |
| Internal memory type | DDR5-SDRAM |
| Internal memory | 32 GB |
| Storage | |
|---|---|
| Internal drive bays | 8 |
| Supported storage drive interfaces | SAS, Serial ATA |
| Hot-swap | Yes |
| Supported RAID controllers | 5350-8i |
| RAID levels | 0, 1, 5, 10, 50 |
| RAID support | Yes |
| Graphics | |
|---|---|
| Maximum graphics card memory | 16 MB |
| On-board graphics card | Yes |
| Network | |
|---|---|
| LAN controller | Broadcom BCM5720 |
| Ethernet LAN | Yes |
| Cabling technology | 10/100/1000Base-T(X) |
| Ethernet interface type | Gigabit Ethernet |
| Ports & interfaces | |
|---|---|
| VGA (D-Sub) ports quantity | 1 |
| Serial ports quantity | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 5 |
| USB 2.0 ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 2 |
| Design | |
|---|---|
| Product colour | Black |
| Chassis type | Tower |
| Performance | |
|---|---|
| Trusted Platform Module (TPM) | Yes |
| Trusted Platform Module (TPM) version | 2.0 |
| Software | |
|---|---|
| Compatible operating systems | Microsoft Windows ServerRed Hat Enterprise LinuxSUSE Linux Enterprise ServerVMware ESXi |
| Power | |
|---|---|
| Power supply input frequency | 50/60 Hz |
| Power supply input voltage | 100 – 240 V |
| Power supply | 800 W |
| Redundant power supply (RPS) support | Yes |
| Operational conditions | |
|---|---|
| Operating altitude | 0 – 3050 m |
| Storage relative humidity (H-H) | 8 – 90% |
| Operating relative humidity (H-H) | 8 – 90% |
| Storage temperature (T-T) | -40 – 60 °C |
| Operating temperature (T-T) | 5 – 45 °C |
| Certificates | |
|---|---|
| 80 PLUS certification | 80 PLUS Platinum |
| General | |
|---|---|
| Product family | ThinkSystem |
| Weight & dimensions | |
|---|---|
| Depth | 578 mm |
| Height | 444 mm |
| Width | 176 mm |
| Technical details | |
|---|---|
| Supported storage drives form factor (rear) | 2.5″ |
