NETGEAR GS308PP Unmanaged Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black
- ETHERNET PORT CONFIGURATION: 8 Gigabit ports
- POWER-OVER-ETHERNET: 8 PoE+ ports with 83W total power budget, and includes NETGEAR FlexPoE making it expandable to 123W (w/separately purchased power supply module)
- PLUG-AND-PLAY: Simple set up with no software to install or configuration needed
- PoE POWER AUTO-BALANCE AND ALLOCATION – NETGEAR’s unique PoE technology automatically balances the PoE power at the most granular level on each port, depending on the device needs
- VERSATILE MOUNTING OPTIONS: Supports desktop, wall or rackmount placement, and includes all the necessary mounting hardware in the box
- SILENT OPERATION: The fanless design means zero added noise wherever its located, making it ideal for noise-sensitive environments
- ENERGY EFFICIENT: Designed to optimize power usage lowering its cost to operate. Most models are compliant with IEEE802.3az Energy Efficient Ethernet mode
- BUILT TO LAST: Every NETGEAR Network switch is rigorously tested for reliability, quality, and performance
NETGEAR 300 Series Gigabit Ethernet Unmanaged Switches with PoE provide easy, reliable, and affordable network connectivity for home and small offices. With these unmanaged plug-and-play switches, you can expand your network connections to multiple devices instantly.
The unmanaged switches provides power and data from a single Ethernet (CAT-5e) cable to devices such as IP cameras, VoIP/ Internet-based phones, wireless access points, etc. The majority of these models also support PoE power auto-balance and allocation feature.
NETGEAR’s unique PoE technology automatically balances the PoE power based on the device needs independent of PoE class detected. These switches deliver the power the device needs, at the most granular level
| Management features |
| Quality of Service (QoS) support |
Yes |
| Switch type |
Unmanaged |
| Ports & interfaces |
| Power connector |
DC-in jack |
| Basic switching RJ-45 Ethernet ports type |
Gigabit Ethernet (10/100/1000) |
| Basic switching RJ-45 Ethernet ports quantity |
8 |
| Network |
| Auto-sensing |
Yes |
| Flow control support |
Yes |
| Auto MDI/MDI-X |
Yes |
| Auto-negotiation |
Yes |
| Full duplex |
Yes |
| 10G support |
No |
| Networking standards |
IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x |
| Data transmission |
| Packet buffer memory |
0.192 MB |
| Packet forwarding rate (1 Gbps) |
1448000 pps |
| Jumbo frames |
9216 |
| Jumbo frames support |
Yes |
| Latency (1 Gbps) |
3 µs |
| Switching capacity |
16 Gbit/s |
| MAC address table |
4000 entries |
| Design |
| Wall mountable |
Yes |
| LED indicators |
Activity, Link, PoE, Power, Speed |
| Housing material |
Metal |
| Product colour |
Black |
| Rack mounting |
Yes |
| Performance |
| Mean time between failures (MTBF) |
2752476 h |
| Power |
| Power consumption (max) |
87.9 W |
| Input current |
1.66 A |
| DC input voltage |
54 V |
| Power over Ethernet (PoE) |
| Total Power over Ethernet (PoE) budget |
130 W |
| Power over Ethernet (PoE) power per port |
30 W |
| Power over Ethernet plus (PoE+) ports quantity |
8 |
| Power over Ethernet (PoE) type supported |
PoE+ |
| Power over Ethernet (PoE) |
Yes |
| Operational conditions |
| Heat dissipation |
300.6 BTU/h |
| Operating altitude |
0 – 3000 m |
| Operating relative humidity (H-H) |
0 – 90% |
| Storage temperature (T-T) |
-20 – 70 °C |
| Operating temperature (T-T) |
0 – 40 °C |
| Weight & dimensions |
| Weight |
600 g |
| Height |
27 mm |
| Depth |
102 mm |
| Width |
236 mm |
| Certificates |
| Certification |
CE Mark, FCC Part 15 Class A, IC Class A, RCM, VCCI,BSMI, KC |
| Logistics data |
| Harmonized System (HS) code |
85176990 |
