Peerless PLAV70-UNL TV mount/stand 165.1 cm (65″) Black
- Up to 180° swivel
- Arm extends up to 32.52″ (826mm) from wall
- +10/-5° of tilt
- ±7° of roll for post installation display leveling
- ±1″ (24mm) vertical adjustment located within reach behind display
- Universal models accommodate 42″ to 65″ displays with mounting hole patterns up to 730 x 433mm (28.75″W x 17.05″H)
- Includes mesh cord sheath and cable ties to neatly manage cables
- Three horizontal arm positions at 2.6″ (66mm) centers for flexible lateral display placement
Designed to handle the heaviest displays, the PLAV70 features dual-arm, all-steel construction that holds displays up to 95″ and weighing up to 200lb. The PLAV7’s self-lubricating bushings enable your display to smoothly articulate, while adjustable tilt and pivot allow you to position your display for the optimal viewing angle. Swing, tilt and extend your display, even in and out of recessed cubby holes and custom frames with the vertical adjustment feature that provides the capability to raise or lower your display for a perfectly aligned installation.
| Mounting |
| Mounting type |
Wall |
| Maximum screen size |
165.1 cm (65″) |
| Minimum screen size |
106.7 cm (42″) |
| Maximum weight capacity |
90 kg |
| Ergonomics |
| Swivel angle range |
0 – 180° |
| Tilt angle range |
-5 – 10° |
| Tilt adjustment |
Yes |
| Design |
| Certification |
UL, GS |
| Housing material |
Steel |
| Product colour |
Black |
| Technical details |
| Quantity per pack |
1 pc(s) |
| Compliance certificates |
RoHS |
| Weight & dimensions |
| Weight |
28.6 kg |
| Height |
429 mm |
| Depth (max) |
82.6 cm |
| Depth (min) |
14 cm |
| Depth |
142 mm |
| Width |
851 mm |
| Packaging data |
| Package weight |
32.9 kg |
| Package height |
600 mm |
| Package depth |
203 mm |
| Package width |
881.1 mm |
| Logistics data |
| Harmonized System (HS) code |
85299097 |
| Other features |
| Screen size compatibility |
1066.8 – 1651 mm (42 – 65″) |
| Dimensions (WxDxH) |
850 x 142 x 550 mm |
| Colour |
No |
| Pivot |
Yes |
| Control type |
Rotary |
