Supermicro X11SRM-VF Intel® C422 LGA 2066 (Socket R4) micro ATX
- Intel LGA 2066 (Socket R4)
- micro ATX Intel® C422
- DDR4-SDRAM Maximum internal memory: 256 GB
- SATA III RAID support
- BIOS type: UEFI AMI ACPI version: 6.0
- Gigabit Ethernet
Major Benefits from Supermicro’s in-house Design Superiority
Supermicro motherboard advantages:
– Technologically-advanced Motherboard Designs Since 1993
– Consistent highest-quality Design, Components, and Production Expertise
– Extensive Range of x86 Serverboards Available
– Competitive Price/Performance
– High Performance Boards Supporting the Latest CPU, memory, and add-on Hardware
– Standard Form Factors offer Feature – rich Support and application optimization
These competitive advantages help Supermicro maintain its design leadership in providing state-of-the-art motherboards for a wide range of applications. Always a step ahead of the competition, Supermicro is consistently first-to-market in delivering high-performance technology support. Offering the most extensive serverboard selection in the industry at competitive prices, Supermicro boards are quality-built to maximize customer satisfaction.
In addition, Supermicro also offers high-performance Embedded motherboards with product life cycles of up to 7 years.
| Processor |
| Processor thermal power (max) |
140 W |
| Processor number of cores supported |
18 |
| Processor socket |
LGA 2066 (Socket R4) |
| Processor manufacturer |
Intel |
| Memory |
| Maximum RDIMM memory |
128 GB |
| Maximum internal memory |
256 GB |
| Supported memory clock speeds |
2133,2400,2666 MHz |
| ECC сompatibility |
ECC & Non-ECC |
| Memory voltage |
1.2 V |
| Supported memory types |
DDR4-SDRAM |
| Storage controllers |
| RAID levels |
0, 1, 5, 10 |
| RAID support |
Yes |
| Supported storage drive interfaces |
SATA III |
| Graphics |
| On-board graphics card model |
Aspeed AST2500 |
| Internal I/O |
| Number of SATA III connectors |
8 |
| Rear panel I/O ports |
| COM ports quantity |
2 |
| VGA (D-Sub) ports quantity |
1 |
| Ethernet LAN (RJ-45) ports |
2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
5 |
| USB 2.0 ports quantity |
6 |
| Network |
| Wi-Fi |
No |
| Ethernet interface type |
Gigabit Ethernet |
| Ethernet LAN |
Yes |
| Features |
| Motherboard chipset |
Intel® C422 |
| Motherboard form factor |
micro ATX |
| Expansion slots |
| PCI Express x16 (Gen 3.x) slots |
1 |
| PCI Express x8 (Gen 3.x) slots |
2 |
| BIOS |
| ACPI version |
6.0 |
| BIOS type |
UEFI AMI |
| Processor special features |
| Trusted Platform Module (TPM) |
Yes |
| Operational conditions |
| Storage relative humidity (H-H) |
10 – 95% |
| Operating relative humidity (H-H) |
10 – 85% |
| Operating temperature (T-T) |
0 – 50 °C |
| Storage temperature (T-T) |
-20 – 60 °C |
| Logistics data |
| Harmonized System (HS) code |
84733020 |
| Weight & dimensions |
| Depth |
243.8 mm |
| Width |
243.8 mm |
| Technical details |
| Compliance certificates |
RoHS |
| Other features |
| Number of DIMM slots |
4 |
| Number of processors supported |
1 |
| Supported RDIMM clock speeds |
2133,2400,2666 MHz |
| Maximum LRDIMM memory |
256 GB |
| Supported LRDIMM clock speeds |
2133,2400,2666 MHz |
| Supported DIMM module capacities |
4GB, 8GB, 16GB, 32GB, 64GB |
| PCI Express x4 (Gen 3.x) slots |
1 |
