TieDex UK Synology Disk Station DS223J – NAS server
Synology Disk Station DS223J – NAS server – SATA 6Gb/s – RAID RAID 0, 1, JBOD – RAM 1 GB – Gigabit Ethernet – iSCSI support
Basic Specifications
- Manufacturer’s Part Number
- DS223J
- EAN
- 4711174724765
- RAM
- 1 GB
- Manufacturer Warranty
- 2-year warranty
- Networking
- 10Mb LAN, 100Mb LAN, 1GbE
- Weight
- 880 g ()
- Product Description
- Synology Disk Station DS223J – NAS server
- Model
- Synology Disk Station DS223J
- Dimensions (WxDxH)
- 10 cm x 22.55 cm x 16.5 cm
- Processor
- 1 x Realtek Semiconductor RTD1619B 1.7 GHz (Quad-Core)
- Power
- AC 100-240 V (50/60 Hz)
- Storage Controller
- RAID SATA 6Gb/s RAID RAID 0, 1, JBOD
- Device Type
- NAS server
- Host Connectivity
- Gigabit Ethernet
- Performance
- Maximum volume size: 108 TB ¦ Maximum number of volume: 64 ¦ Maximum concurrent connections: 200 ¦ Local user account: 1024 ¦ Local group account: 256 ¦ Maximum number of shared folder: 256 ¦ Maximum number of shared folders syncing tasks: 4 ¦ Hybrid share folder number: 5 ¦ Syslog: 400 events per second
- IP Cameras Supported
- 12
- Max Supported Capacity
- 108 TB
General
- Device Type
- NAS server
- Host Connectivity
- Gigabit Ethernet
- Max Supported Capacity
- 108 TB
- Width
- 10 cm
- Depth
- 22.55 cm
- Height
- 16.5 cm
- Weight
- 880 g ()
Miscellaneous
- Cables Included
- 1 x network cable
- Features
- 92mm cooling fan
- Compliant Standards
- FCC, BSMI, VCCI, RCM, UKCA, EAC, CCC, KC, RoHS
- Included Accessories
- Accessory pack, power cable
Manufacturer Warranty
- Service & Support
- Limited warranty – 2 years
Networking
- Data Link Protocol
- 10Mb LAN, 100Mb LAN, 1GbE
- Network / Transport Protocol
- SMB, NFS, FTP, CIFS, SMB v2, SMB v3, iSCSI, HTTP, HTTPs
- Remote Management Protocol
- HTTP, HTTPS, SNMP, LDAP
- Network Services Compatibility
- Apple File Protocol (AFP), Server Message Block (SMB), Network File System (NFS), FTP, Web-based Distributed Authoring and Versioning (WebDAV), Server Message Block 2.0 (SMB 2.0), Server Message Block 3.0 (SMB 3.0), Network File System v3 (NFS v3), Network File System v4 (NFS v4), Network File System v4.1 (NFS v4.1), Calendaring Extensions to WebDAV (CalDAV), HTTP, HTTPS
- Performance
- Maximum volume size: 108 TB ¦ Maximum number of volume: 64 ¦ Maximum concurrent connections: 200 ¦ Local user account: 1024 ¦ Local group account: 256 ¦ Maximum number of shared folder: 256 ¦ Maximum number of shared folders syncing tasks: 4 ¦ Hybrid share folder number: 5 ¦ Syslog: 400 events per second
- Features
- Hardware encryption, USB One Touch Copy, B-tree file system (Btrfs), EXT4 file system, wake on LAN (WOL), wake on WAN (WOW), SSD trim, Access Control List (ACL) support, NFS Kerberos authentication, VPN Server, cloud sync
- Compliant Standards
- DLNA CERTIFIED
Expansion / Connectivity
- Expansion Bays
- 2 (total) / 2 (free) x hot-swap – 2.5″ / 3.5″
- Interfaces
- 3 x USB 3.2 Gen 1 – Type A ¦ 1 x Ethernet 1000Base-T – RJ-45
Power
- Power Device
- External power adapter
- Voltage Required
- AC 100-240 V (50/60 Hz)
- Power Consumption Operational
- 16.31 Watt
- Power Consumption Stand by
- 4 Watt
- Power Provided
- 60 Watt
Storage Controller
- Type
- RAID
- Interface Type
- SATA 6Gb/s
- RAID Level
- RAID 0, RAID 1, JBOD
Environmental Parameters
- Min Operating Temperature
- 0 °C
- Max Operating Temperature
- 40 °C
- Humidity Range Operating
- 5 – 95% RH
- Sound Emission
- 18.2 dBA
Processor / Memory
- Processors Installed
- 1 x Realtek Semiconductor RTD1619B 1.7 GHz
- Number of Cores
- Quad-Core
- Max Supported Qty
- 1
- RAM
- 1 GB DDR4
Security DVR
- IP Cameras Supported
- 12
- Compression Format
- H.264, H.265
- Image Resolution
- 1280×720, 1920×1080, 2048×1536, 2591×1944, 3840×2160
