Vertiv GI10095 power distribution unit (PDU) 36 AC outlet(s) 0U Black
- The Combination Outlet C13 / C19 is a 2-in-1 receptacle functioning as both an IEC C13 and C19. Simplify the rack PDU buying process and accommodate ever-changing rack power requirements.
- High retention outlets reduce the risk of costly downtime from accidental disconnections of the power cord.
- Simplify cable management with the Combination Outlet C13 / C19 by simply connecting equipment to the closest available receptacle.
- The Combination Outlet C13 / C19 meets global electrical compliance requirements and is UL Certified and CE Marked.
- Standard three-year warranty, upgraded to a five-year warranty with product registration.
Upgradeable Metered rPDUs provide reliable power distribution to critical IT equipment within a rack or cabinet while delivering a view of real-time view of power usage from a local LED display.
| Design | |
|---|---|
| Product colour | Black |
| Mounting | Vertical |
| Rack capacity | 0U |
| PDU types | Monitored |
| Ports & interfaces | |
|---|---|
| AC outlets quantity | 36 AC outlet(s) |
| Features | |
|---|---|
| Cable length | 3 m |
| Power | |
|---|---|
| Load capacity | 7400 VA |
| Maximum current | 32 A |
| AC input frequency | 50 Hz |
| Nominal input voltage | 230 V |
| Certificates | |
|---|---|
| Certification | – CE Marked- RoHS Compliant |
| Compliance certificates | RoHS |
| Operational conditions | |
|---|---|
| Operating altitude | 0 – 3050 m |
| Operating relative humidity (H-H) | 5 – 95% |
| Storage relative humidity (H-H) | 5 – 95% |
| Operating temperature (T-T) | 0 – 60 °C |
| Weight & dimensions | |
|---|---|
| Weight | 7.26 kg |
| Height | 51 mm |
| Depth | 51 mm |
| Width | 1683 mm |
