Zebra 220Xi4 label printer Thermal transfer 203 x 203 DPI Wired Ethernet LAN
- Thermal transfer
- 203 x 203 DPI
- Maximum printing width: 21.6 cm
- Built-in barcodes: 1D, 2D, CODABAR (NW-7), Code 128 (A/B/C), Code 39, Code 49, Code 93, EAN13, EAN8, Industrial 2/5, Interleaved 2/5, MaxiCode, PDF417, POSTNET, QR Code, UPC-A, UPC-E
- Connectivity technology: Wired
- USB port Ethernet LAN
- Display: LCD 240 x 128 pixels
- 32.7 kg
Built for high-volume applications and harsh environments, Zebra’s Xi Series label printers deliver superior print quality and reliability. Boost productivity with faster print and connection speeds, and reduce downtime with early warning.
Used For:
– Asset Management
– Cross Docking
– Inventory Management
– Receiving/Shipping
– Work-in-Process Tracking
– Compliance Labeling
– Order Labeling
– Quality Control
220Xi4 Industrial Printer
Designed for fast printing of chemical drum and other wide-label applications, count on high-performance when you trust the rugged reliability of this thermal label printer.
| Printing |
| Maximum printing width |
21.6 cm |
| Maximum resolution |
203 x 203 DPI |
| Colour |
No |
| Print technology |
Thermal transfer |
| Paper handling |
| Media thickness |
0.076 – 0.305 mm |
| Maximum label width |
22.4 cm |
| Maximum roll diameter |
20.3 cm |
| Core diameter |
7.6 cm |
| Media thickness (imperial) |
0.003 – 0.12″ |
| Ribbon length |
450 m |
| Ribbon width |
17 cm |
| Ports & interfaces |
| Optional connectivity |
Twinax, Wireless LAN |
| Standard interfaces |
Ethernet |
| RS-232 interface |
Yes |
| RS-232 ports |
1 |
| Parallel ports quantity |
1 |
| USB 2.0 ports quantity |
1 |
| USB port |
Yes |
| Wi-Fi |
No |
| Ethernet LAN |
Yes |
| Connectivity technology |
Wired |
| Performance |
| Certification |
BSMI, cTUVus, CCC, CE, C-Tick, EN55022 B, EN55024, EN61000-3-2,3, FCC B, GOST-R, ICES-003 B, IEC 60950-1 / EN60950, KCC, NOM, S Mark, STB, UkrSEPRO, VCCI, ZIK |
| Processor frequency |
133 MHz |
| Built-in processor |
32-bit RISC |
| Built-in barcodes |
1D, 2D, CODABAR (NW-7), Code 128 (A/B/C), Code 39, Code 49, Code 93, EAN13, EAN8, Industrial 2/5, Interleaved 2/5, MaxiCode, PDF417, POSTNET, QR Code, UPC-A, UPC-E |
| Flash memory |
8 MB |
| Internal memory |
16 MB |
| Page description languages |
XML, ZPL, ZPL II |
| Design |
| Display resolution |
240 x 128 pixels |
| Display |
LCD |
| Built-in display |
Yes |
| Product colour |
Black, Grey |
| Power |
| Power requirements |
90 – 264 VAC, 48 – 62 Hz |
| Operational conditions |
| Operating temperature (T-T) |
5 – 40 °C |
| Storage temperature (T-T) |
-40 – 60 °C |
| Storage relative humidity (H-H) |
5 – 85% |
| Operating relative humidity (H-H) |
20 – 85% |
| Weight & dimensions |
| Weight |
32.7 kg |
| Height |
393.7 mm |
| Depth |
517.5 mm |
| Width |
401.6 mm |
| Packaging data |
| Package type |
Box |
| Packaging content |
| Cables included |
AC |
| Logistics data |
| Harmonized System (HS) code |
84433210 |
| Technical details |
| Sustainability certificates |
ENERGY STAR |
| Other features |
| Network ready |
Yes |
